230′ Fincantieri Yachts 2026 PLATINUM X

SPECIFICATIONS

Length: 230′ 0″ (70.10)
Beam: 39′ 4″ (11.99m)
Draft: 11′ 6″ (3.51m)
Year: 2026
Builder: Fincantieri Yachts
Model: Preferred Builder – Fincantieri Yachts
Hull Material: Steel
Gross Tonnage: 1535
Engines: 2x Caterpillar
Cruising speed: 13 Knots
Max speed: 17 Knots
Staterooms: 6
Guests: 12
Total Crew: 15
Location: Italy

CONSTRUCTION

Preferred Builder – Fincantieri Yachts

Materials
Hull to Be Built in Marine Grade Tensile Steel Ah 36 / Marine Grade Sea Water Resistant Aluminum Made Superstructure (With Exclusion of Full Beam Hull Sides to Be Made in High Tensile Steel).

Classification/flag
Lloyd’s Register 100a1, Ssc, Yacht Mono G6, Lmc, Ums, Scm, Eco
The Yacht Shall Comply With the Red Ensign Yacht Code Part a.

Design
The Exterior Lines Are Designed by Christopher Seymour in Close Cooperation With Design Consultant Carl Esch, and Interior Design Concept by Sorin Vega

EXTERIOR

Hull, Topsides and Superstructure Will Be Faired and Painted by Using a High-grade Yacht Exterior Painting in Non-metallic Light Colors.

Teak Decks With First-class Grade Quarter-sawn 55mm Wide Teak
Polished Stainless-steel Exterior Railing of Circular Tubes
Glass Windscreens
Tinted Laminated Windows

DECK EQUIPMENT

One Stern Passerelle
Side Boarding Ladder on Starboard With Self-leveling Teak Steps
Two (2) Vertical Anchor Winches With Warping Head
Dedicated Rescue Boat Storage Under Foredeck With Overhead Crane, Accessible via Hatch
Two (2) Capstans and Four (4) Bollards on Each Side at Main Deck
Two (2) Overhead Crane Beams Used for Launching the Tender Boats and Wave Runners
Telescopic Foremast
One (1) Jacuzzi on Top Deck With Seats and Sun Beds
One (1) Pool on Main Deck Aft and (1) Pool on Bridge Deck, With Mosaic Inlay and Pool Tank
Two (2) Anchor Mooring Hatches for Better Crew Visibility During Anchoring and Mooring
Bottom Hinged Shell Door Used as Side Balcony for Aft Leisure Beach Area at Lower Deck
Concealed Automatic Controlled Sun Canopy at Forward Bridge Deck
Optional Feature; Two (2) Large Folding Side Balconies to Port- and Starboard Side Owners Cabin in Deck
Optional Feature; a Foldable Platform at the Swimming Platform to Enlarge the Aft Area

INTERIOR AND ACCOMMODATION

Luxury Staircase Serving Lower and Main Decks
Luxury Open Style Staircase Connecting Main Saloon and Sky-lounge
Crew Staircase Serving Main Deck and Bridge Deck
Square Elevator Serving Three Decks
Central Galley on Main Deck, With Direct Connection to Pantry Bridge Deck & Main Saloon
Large Pantry at Bridge Deck
Owners Suite, With Dressing & Bathroom, and Private Office/library at Main Deck, Convertible Into Two Large Separate Cabins
Large Open Sun Decks With Lounges, Dining, Large Bar and Access Stairway
Four (4) Large Luxurious Guest Cabins at Lower Deck
Food Lift Serving Decks (on Request)
Tender Garage Which Can Be Converted Into a Leisure Area for Guests With Bar
Large Enclosed Area on the Top Deck Facing Aft and Forward Open Areas

INTERIOR SPACES

Owners and Guests Approx. 485 Sqm
Dual Purpose Tender Garage / Guest Leisure Area Approx. 110 Sqm
Crew Area’s (Without Technical Areas) Including Wheelhouse Approx. 220 Sqm
Catering (Galley and Pantry´s) & Laundry Areas Approx. 58 Sqm
Service and Technical Areas (Storage Areas) Approx. 92 Sqm

Ceiling Heights
Main Deck 2.20m (Under Domes Approx. 2.30m)
Bridge and Top Deck 2.10m (Under Domes Approx. 2.20m)
Guest Cabins and Crew Area Lower Deck 2.10m

ENTERTAINMENT SYSTEMS

Full Entertainment System With Satellite TV/ Audio
Video on Demand
Internet in Saloons, Guest Cabins and Owners’ Areas

NAVIGATION EQUIPMENT

Integrated Navigation System
Gyro and Magnetic Compass
X-band Radar
S-band Radar
Autopilot
Speed Log
Echo Sounder
DGPS
ECDIS
Conning
Wind Measurement Equipment
AIS

COMMUNICATION SYSTEMS

Communication According to Gmdss Area 3, Inmarsat F, Intercom, Telephone Installation

VENTILATION AND AIR CONDITIONING

A Centralized, Single Duct (Variable Air Volume (VAV) in the Owner’s and Guest Areas) Air Conditioning System for Interior Owner/Guest/Crew Living Areas

FIRE FIGHTING AND SAFETY EQUIPMENT

A High-pressure Water Mist Fire Extinguishing System Is Fitted to Protect the Accommodation, Service and Machinery Spaces.

Automatic Watertight Sliding Doors to Divide the Ship in Case of Hull Damage With Appropriate Means of Escape in Case of Emergency. An Alarm and Monitoring System Is Provided.

ELECTRICAL INSTALLATION

The Diesel Generators Configuration Consists of Three (3) Diesel Generators (Caterpillar or Equivalent) for Total Power of Approx. 600 kW, 3 Phase 400V, 50 Hz. Each Generator Is Foreseen to Be Double Elastic Mounted and Fitted With a Suitable Sound Enclosure. An Emergency Generator Set According to Rules & Regulations, and Shore Power With Characteristics to Be Based on Final Electric Load Balance

EXTERIOR LIGHTING

A Customized Luxury Exterior Led Lighting Scheme Based on the Exterior Design, Underwater Lights Included

MAIN MACHINERY

Propulsion
The Main Propulsion Plant Consists of Two (2) Diesel Engines (Caterpillar or Equivalent), Each Coupled to a Fixed Pitch Propeller (Fpp) Through Reduction Gear Box and Shaft Line. Each Main Propulsion Diesel Engine Is Foreseen With Single Elastic Mounting and Elastic Coupling to Gearbox. Gearboxes Will Be Hard Elastic Mount. Maximum Speed Is 17,0 Knots.

Exhaust
The Exhaust Gases of the Propulsion Engines Will Be Led Underwater to the Side Shell, Bypass for Low Operations Will Be Lead to the Side Shell Above Waterline. The Exhaust Gases of the Diesel Generators Will Be Led Through the Funnel.
Dry Silencers and Urea-based Selective Catalyst Reduction (Scr) Systems Will Be Fitted on All Exhaust Lines to Fulfil the Imo Tier Ill Rules Requirements on Nox Emissions. Soot Filters Are Foreseen on the Diesel Generators Exhaust Lines.

Bow Thruster
Tunnel Mounted Electrically Driven of Abt 160 Kw

Stabilizers
Underway and Anchor Mode Stabilizer Non-retractable and Hydraulically Operated

WATER SYSTEMS

Fresh Water System
Two Hydrophore Pumps
Three Hot-water Boilers
Hot and Cold Water Circulation System
Two Reverse-osmosis Water Makers With Capacity of 10 Tons/each Per Day

Sewage Treatment System
Vacuum Toilet Sanitary System
Black-water Treatment

HELICOPTER PAD

A Non-certified Helicopter Touch and Go Landing Place on Bridge Deck Forward, Suitable to Support a Helicopter Operations With Maximum Take-off Weight of Approx. 3000kg. (E.g. Eurocopter H135)

TENDER AND TOYS

Enclosed Aft Ship Tender Store With Bottom-hinged Side Doors Suitable for: Two (2) 8-meter Tenders, Four (4) Jet Skis, and Water Toys.
